SPR 510R - ENDURO
Break boundaries!
Unleash raw power and performance with the SPR 510R unbridled beast.
The 501cc engine with 6-speed transmission and ZF Sachs® suspension pack offers the perfect package.
ENGINE
The 501cc liquid-cooled DOHC engine of the SPR 510R is developed from the race-proven SPR 310R engine, providing increased power and torque.
Its lightweight design and explosive attitude make it unsuitable for faint-hearted riders. To ensure control at all times, the 510R is fitted with a precisely tuned Athena® ECU.
FRAME AND CHASSIS
Unleash unmatched performance and reliability with AJP SPR 510R Enduro's hybrid steel and aluminum frame.
The flexible geometry offers versatility for every rider, delivering unparalleled throttle response and rock-solid reliability.
SUSPENSION AND BRAKES
The ZF Sachs® Ø48mm suspension on the SPR 510R is fully adjustable with closed cartridges, giving you confidence and tune-ability for any type of riding.
The suspension setup offers intuitive tuning and maintenance-free technology.
TECHNICAL SPECS
ENGINE
| TYPE | Single-cylinder - 4S |
| SYSTEM | DOHC - 4v |
| COOLING SYSTEM | Liquid |
| DISPLACEMENT | 501cc |
| BORE X STROKE | 97 x 67.5mm |
| STARTER | Electric |
| FUEL SYSTEM | ATHENA GET® Injection System Ø45mm |
| CLUTCH | Oil bath, multi-disc |
| TRANSMISSION | 6 speed |
CHASSIS
| FRAME | Aluminium-steel composite |
| WHEELBASE | 1450mm |
| SEAT HEIGHT | 960mm |
| GROUND CLEARENCE | 355mm |
| FUEL TANK | 9.5L |
WHEELS
| FRONT | 90/90 21" |
| REAR | 140/80 18" |
BREAKS
| FRONT CALIPER | BRAKTEC® Dual Piston |
| FRONT DISC | Ø260mm |
| REAR CALIPER | BRAKTEC® Single Piston |
| REAR DISC | Ø220mm |
SUSPENSION
| FRONT | ZF SACHS® Ø48mm Double Closed cartridge fork |
| FRONT TRAVEL | 300mm fully adjustable |
| REAR | ZF SACHS® prog. system w/ reservoir |
| REAR TRAVEL | 300mm |
